Printer Maintenance Chapter 10

10-4 428T Operator’s Manual- 880037-0141

Figure 10-4 Internal Cleaning

10.4 Print Head Maintenance

If print quality has not improved after using a thermal cleaning card, or if one is not

available, foam or cotton tipped swabs or a clean lint-free cloth dampened with isopropyl

alcohol may be used. Follow the steps below to clean the print head.

1. Release the Print Head Assembly and rotate to the open position.

2. With a foam or cotton tipped swab or soft, lint-free cloth dampened with isopropyl

alcohol, clean the thermal elements by gently rubbing the swab down the length of

the print head dot row. Allow for the alcohol to evaporate, then repeat if necessary.

3. Reinstall media and run labels to check print quality.

4. If poor print quality persists, print head or other parts may be damaged.

CAUTION: Isopropyl Alcohol or other approved non-Abrasive

solution should be used to

clean the drive roller. The use of other

cleaning solvents or materials is not recommended and may

degrade the performance of the drive roller.

Blow dust out with

compressed air or

vacuum with anti-static

vacuum cleaner.

Clean Paper Path with

lint-free cloth or swabs

dampened with isopropyl

alcohol.

Clean Drive Roller with

lint-free cloth or swabs

dampened with isopropyl

alcohol. (Drive Roller

can be rotated by hand.)
